UAV engine EFI installation manual-DLE120-V1.4
Copy right ECOTRONS LLC http://www.ecotrons.com
3.2 ECU broadcast data list on CAN bus
3.2.1 The CAN Baud rate setting of ECU
Our ECU and tuning software (EcoCAL) support the CAN communication, you can
change the baud rate by yourself.
Note: There should be a 120 ohm resistor between the CAN wires, and our ECU
doesn’t have the 120 ohm termination resistor, so you need add it by yourself in
the CAN connector, see below picture,
