Introduction
UAV EFI for DLE engine is an Electronic Fuel Injection conversion kit for the UAV engine.
It is a bolt-on EFI kit to a lot of small engines. For example, DLE-40, DLE-60, DLE-120,
DLE-170 etc. We can supply the suitable EFI kit for most of UAV engines. The
displacement of the engines can be in the range of 20cc to 300cc, and even larger
engines.
This UAV EFI kit has below features:
 Electronic fuel injection (EFI)
 Quick engine start even at cold temperatures
 More power and torque than the carbureted version
 High fuel efficiency and low carbon emissions
 OBD - on board diagnosis
 Performance tuning for advanced users.
 Altitude compensations
 Transient fuel compensations
 Servo motor control (optional)
 Ignition control (optional)
Parts:
1. ECU
2. Harness (including the connectors)
3. Throttle Body
 Throttle body
 Servo motor(included)
 TPS sensor(optional)
 Fuel injector (mounted on the throttle body)
4. Fuel pump assembly
 Rotary fuel pump with pressure regulator (outside of the tank, 25L/h))
5. Baro sensor (integrated in ECU)
6. Engine temperature sensor
7. Intake air temperature sensor
8. Ecotrons CDI - ECU controlled (optional, you can use your own CDI).
