ECS A55F-M3 User Manual

42
Using BIOS
This page enables you to set the keyboard NumLock state.
Boot Menu
Boot Configuration
This item shows the information of the Boot Configuration.
Bootup NumLock State (On)
This item enables you to select NumLock state.
Set Boot Priority
This item enables you to select boot priority for all boot devices.
1st/2nd/3rd/4th/5th/6th/7th/8th Boot
These items shows the boot priorities.
CD/DVD ROM Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing CD/DVD ROM drives.
USB Floppy/Floppy Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB Floppy/Floppy drives.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.13.1216. Copyright (C) 2011 American Megatrends, Inc.
Select the keyboard NumLock
state
Boot Configuration
Bootup NumLock State [On]
Set Boot Priority
1st Boot [Hard Disk]
2nd Boot [CD/DVD]
3rd Boot [USB Floppy/Floppy]
4th Boot [USB CD/DVD]
5th Boot [USB Hard Disk]
6th Boot [USB KEY]
7th Boot [Network]
8th Boot [UEFI]
CD/DVD ROM Drive Priorities
Hard Disk Drive Priorities
USB Floppy/Floppy Drive Priorities
USB CD/DVD ROM Drive Priorities
USB HardDisk Drive Priorities
USB KEY Drive Priorities
NETWORK Device Priorities
UEFI Boot Drive Priorities
Main Advanced Chipset M.I.B.III Boot Security Save & Exit
























Hard Disk Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing hard disk drives.
USB CD/DVD ROM Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB CD/DVD ROM drives.
USB HardDisk Drive Priorities
This item enables you to specify the sequence of loading the operating system from
the installing USB HardDisk drives.
Enter/Dbl Click : Select
+/- : Change Opt.


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit

ECS A55F-M3 Specifications

General

Memory channels	Dual-channel
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600, 1866 MHz
Processor socket	Socket FM1
Processor manufacturer	AMD
Compatible processor series	AMD Athlon X2 Dual-Core, AMD Sempron
USB 2.0 connectors	2
Power fan connector	Yes
Number of COM connectors	1
Number of SATA II connectors	4
Number of Parallel ATA connectors	0
Headphone outputs	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	VIA VT1705
Component for	PC
Power source type	ATX
Motherboard chipset	AMD A55
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows XP, Vista
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA II
On-board graphics card	No
Parallel processing technology support	Not supported
LAN controller	Realtek RTL8111E
Networking features	Gigabti Ethernet
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AMI
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	180 mm
Width	230 mm
