Setting Up AMD A55 RAID Configuration
The BIOS CMOS Setup Utility screen appears.
Setting Up a bootable RAID Array
This section explains how to configure a bootable AMD RAID array.
Setting Up the BIOS
Use the arrow keys to select Advanced menu (see Figure 1.1), then select
SATA Configuration and press Enter.
Figure 1.2 SATA Configuration Screen
Use the arrow keys to select the SATA Configuration (see Figure 1.2) and
globally set SATA Configuration to RAID.
Start your computer, then press Delete to enter the BIOS setup.
Figure 1.1 BIOS CMOS Setup Utility Main Screen
1
2
3
Chapter 6
Setting Up AMD A55 RAID Configuration
BIOS Information
System Language [English]
System Date [Tue 07/19/2011]
System Time [16:52:28]
Choose the system default
language
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Version 2.13.1216. Copyright (C) 2011 American Megatrends, Inc.
SATA Configuration
Serial-ATA Controller [Enabled]
SATA Mode [IDE]
SATA Port1 Not Present
SATA Port2 Not Present
SATA Port3 Not Present
SATA Port4 Not Present
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset M.I.B.III Boot Security Save & Exit
Version 2.13.1216. Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset M.I.B.III Boot Security Save & Exit
Enter/Dbl Click : Select
+/- : Change Opt.
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Enter/Dbl Click : Select
+/- : Change Opt.
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
