Setting Up AMD A55 RAID Configuration

Select [2], then select LD 1 in the following page.

The Define LD Menu screen appears (Figure 1.4).

Figure 1.4 Define LD Menu

Using the Define a New Array Screen

If necessary, press the tab key to move from field to field until the appropriate field

is highlighted.

• Selecting the RAID Mode

By default, this is set to Mirroring. To change to a different RAID mode,

press the spacebar until the mode that you want appears in the RAID Mode

box—RAID0/1/10/JBOD.

Note: Not all RAID levels are supported on all platforms.

Stripe block size is given in kilobytes, and affects how data is arranged on the

disk. It is recommended to leave this value at the default Optimal, which is

64KB, but the values can be 64 KB and 128 KB. When choose RAID 1, the

Stripe block size is unchangeable.

• Selecting the Stripe Block Size

Note: If you want to use the function of the following RAID Mode, you have

to install enough HDD.

RAID READY (1 piece of HDD); RAID 0,1 ,JBOD (2 or more pieces of

HDD); RAID 0+1 (4 pieces of HDD)

[

m] Up [

n] Down [ESC] Exit [Space] Change Option [Ctrl-Y] Save

[ Define LD Menu ]

[ Keys Available ]

LD No RAID Mode Total Drv

LD 1 RAID 0 0

Stripe Block : 64 KB Past Init : OFF

Gigabyte Boundary : ON Cache Mode : WriteThru

Channel : ID Drive Model Capacity (MB) Assignment

3 : Mas WDC WD3200AAJS-22B4 320073 N

4 : Mas WDC WD1600JS-22NVB1 160042 N

[ Drives Assignments ]
