ECS B350AM4-M User Manual

Chapter 3
B350AM4-M USER MANUAL
37
CPU Configuration
The item in the menu shows the CPU.
Main Advanced Chipset M.I.B. X Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Enable/disable C6
CPU Configuration
Socket0: AMD Ryzen: ZD3301BBM6IF4_37/33_Y
6 Core(s) Running @ 3345 MHz 1275 mV
Processor Family: 17h
Processor Model: 00h-0Fh
CPUID: 00800F11
Max Speed: 3300 MHz
Min Speed: 1550 MHz
Microcode Patch Level: 800111C
------------- Cache per core -------------
L1 Instruction Cache: 64 KB/4-way
L1 Data Cache: 32 KB/8-way
L2 Cache: 512 KB/8-way
No L3 Cache per Socket: 16 MB/16-way
C6 Mode Enabled
AMD Turbo Core Auto
AMD C&Q Enabled
Socket0: AMD A8-9600 RADEON R7, 10 COMPUTE CORES 4C+6G 4 Core(s) Running @
3124 MHz 1125 mV
This is display-only field and displays the information of the CPU installed in your
computer.
Main Advanced Chipset M.I.B. X Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Enable/disable C6
CPU Configuration
Socket0: AMD A8-9600 RADEON R7, 10 COMPUTE CORES 4C+6G
4 Core(s) Running @ 3124 MHz 1125 mV
Processor Family: 15h
Processor Model: 60h-6Fh
CPUID: 00660F51
Max Speed: 3100 MHz
Min Speed: 1400 MHz
Microcode Patch Level: 6006118
------------- Cache per core -------------
L1 Instruction Cache: 96 KB/3-way
L1 Data Cache: 32 KB/8-way
L2 Cache: 512 KB/16-way
No L3 Cache Present
C6 Mode Enabled
AMD Turbo Core Auto
AMD C&Q Enabled
