ECS B350AM4-M User Manual

69
B350AM4-M USER MANUAL
Chapter 5
Chapter 5
Setting Up AMD B350 RAID Configuration
Setting Up a bootable RAID Array
This section explains how to configure a bootable AMD RAID array.
1. Start your computer, then press Delete to enter the BIOS setup. The BIOS
Setting Up the BIOS (Under Windows 7)
2. Use the arrow keys to select Advanced menu (see Figure 1.2), then select
SATA Configuration and press <Enter>. Globally set SATA Configuration to
RAID.
Main screen appears.
Enabled/Disabled Serial ATA
Main Advanced Chipset M.I.B. X Security Boot Exit
SATA Configuration
SATA Controller Enabled
SATA Mode AHCI
SATA Port1 Not Present
SATA Port2 Not Present
SATA Port3 ST10000DM003-1E (1000.2...
SATA Port4 Not Present
SATA Port5 (M.2) Not Present
Choose the system default
language
Main Advanced Chipset M.I.B. X Security Boot Exit
BIOS Information
System Language English
System Date Fri 06/02/2017
System Time 00:00:16
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Figure 1.1 BIOS Main Screen
Figure 1.2 SATA Configuration Screen
