Chapter 3
B350AM4-M USER MANUAL
48
Main Advanced Chipset M.I.B. X Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Disable - disable this
Pstate Custom - customize
this Pstate, applicable only
if Pcd0cDisable=FALSE
WARNING - DAMAGE
CUASED BY USE OF
YOUR AMD PROCES-
SOR OUTSIDE OF
SPECIFICATION OR IN
EXCESS OF FACTORY
SETTINGS ARE NOT
COVERED UNDER
YOUR AMD PRODUCT
WARRANTY AND MAY
NOT BE COVERED BY
YOUR SYSTEM
MANUFACTURER’S
WARRANTY.
Operating your AMD
processor outside of
specification or in excess
of factory settings,
including but not limited to
overclocking, may damage
or shorten the life of your
processor or other
Accept
Custom Pstate0 Custom
Pstate0 Frequency Set (Mhz) 3100
Pstate0 Voltage Set (uV) 1187500
Frequency (MHz) 3100
Voltage (uV) 1187500
Pstate0 FID 124
Pstate0 DID 8
Pstate0 VID 58
Custom Pstate1 Auto
Custom Pstate2 Auto
Custom Pstate3 Auto
Custom Pstate4 Auto
Custom Pstate5 Auto
Custom Pstate6 Auto
Custom Pstate7 Auto
Pstate0 Frequency Set (Mhz)
Use this item to set Pstate0 frequency, 2800 Mhz - 6000 Mhz, each step is 25 Mhz.
Pstate0 Voltage Set (uV)
Use this item to set Pstate0 voltage, 1050000uV(1050mV) - 1550000uv(1550mV),
each step is 6250uV(6.25mV).
Press <Esc> to return to the Custom Core Pstats page.
Press <Esc> to return to the Zen Common Options page.
