B75H2-M USER MANUAL
36
Chapter 3


PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
CPU Temperature (DTS)
This item shows the CPU DTS data for thermal reference.
System Ambient Temperature
This item shows the system Ambient temperature.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU voltage, CPU & system fan speed...etc.
• PCH Temperature
• CPU Fan Speed
• System Fan Speed
• CPU Core
• + 1.05V
• + 3.30V
• + 5.00 V
• + 12.0V
• 5VSB
BIOS Setup Utility
CPU Temperature (DTS) : 38
System Ambient Temperature : 27°C/80°F
PCH Temperature : 44
CPU Fan Speed : 1057 RPM
System Fan Speed : N/A
CPU Core : 1.056 V
+1.05V : 1.056 V
+3.30V : 3.345 V
+5.00V : 5.100 V
+12.0V : 12.168 V
5VSB : 4.980 V
System Shutdown Temperature [Disabled]
CPU Shutdown Temperature [Disabled]
Smart Fan [Enabled]
System Shutdown Temperature

+/-/Spacebar : Change Opt.
Enter : Select
F7: Load User default Settings

:Move
F8: Save as User Default
Settings
F9: Load Default Settings
F10: Save & Exit Setup
ESC: Discard changes and Exit
Setup
Version 2.15.1227. Copyright (C) 2002-2012, Inc.
Main
Advanced Power Authentication Security Boot Options Exit
