ECS B75H2-M2 User Manual

5
B75H2-M2B75H2-M2
B75H2-M2B75H2-M2
B75H2-M2 USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket LGA1155 socket
2. CPU_FAN 4-pin CPU cooling fan connector
3. DDR3_1~2 240-pin DDR3 Module slots
4. ATX_POWER Standard 24-pin ATX power connector
5. SYS_FAN 3-pin system cooling fan connector
6. PWR_FAN 3-pin power cooling fan connector
7. SATA2~5 Serial ATA 3.0 Gb/s connectors
8. SATA1 Serial ATA 6.0 Gb/s connector
9. F_PANEL Front panel switch/LED header
10. CASE CASE open header
11. ME_UNLOCK ME unlock header-for factory use only
12. F_USB1~2 Front panel USB 2.0 headers (F_USB1 supports EZ Charger)
13. USB3F Front panel USB 3.0 header
14. TPM Trusted Platform Module header
15. CLR_CMOS Clear CMOS jumper
16. SPDIFO SPDIF out header
17. F_AUDIO Front panel audio header
18. SPK Speaker header
19. PCIE1~3 PCI Express x1 slots
20. PCIEX16 PCI Express slot for graphics interface
21. ATX12V 4-pin +12V power connector

ECS B75H2-M2 Specifications

General

Brand	ECS
Model	B75H2-M2
Category	Motherboard
Language	English
