B85H3-M7 USER MANUAL

Chapter 3

System Component Characteristics

These items display the monitoring of the overall inboard hardware health events,

such as CPU fan speed, DIMM voltage... etc.

Press <Esc> to return to the Advanced Menu page.

Smart Fan Mode (Normal)

This item allows you to select the fan mode (Normal, Quiet, Silent, or Manual) for a

better operation environment. If you choose Normal mode, the fan speed will be

auto adjusted depending on the CPU temperature. If you choose Quiet mode, the

fan speed will be auto minimized for quiet environment. If you choose Silent mode,

the fan speed will be auto restricted to make system more quietly. If you choose

Manual mode, the fan speed will be adjusted depending on users’ parameters.

Press <Esc> to return to the PC Health Status page.

Smart Fan Start PWM value (180)

Smart Fan Start TEMP(DTS) (45)

This item is used to set the start PWM value of the smart fan.

This item is used to set the start temperature of the smart fan.

DeltaT (+3)

This item specifies the range that controls CPU temperature and keeps it from going

so high or so low when smart fan works.

Smart Fan Slope PWM value (10 PWM value/unite)

This item is used to set the Slope Select PWM of the smart fan.

This item is used to set the CPU/System fan full speed offset value.

CPU/System Fan Full Speed Offset(DTS) (52)

• CPU Temperature (DTS)

• System Temperature

• CPU Fan Speed

• System Fan Speed

• Processor Input Voltage

• DIMM Voltage

Questions and Answers:

Need help?

Do you have a question about the ECS B85H3-M7 and is the answer not in the manual?

ECS B85H3-M7 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1666 MHz
System bus rate	5 GT/s
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	2
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	4
Supported storage drive interfaces	SATA II, SATA III
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111G
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC662
Certification	CE/FCC \\r ErP/EuP \\r WHQL \\r WHCK
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® B85
Audio output channels	5.1 channels
Motherboard form factor	mini ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
BIOS type	AMI
ACPI version	5.0
BIOS memory size	64 Mbit
