B85H3-M7 USER MANUAL
50
Chapter 3
Use this item to enable/disable Package Current Lock.
Package Current Lock (Disabled)
IA Core Current (Maximum)
)
Use this item to control CPU Current Limit.
Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST (Enhanced Intel SpeedStep Tech-
nology).
Turbo Mode (Enabled)
This item allows you to control the Intel Turbo Boost Technology.
Boot Performance Mode (Max Non-Turbo Perfor...)
Use this item to select the performance state that the BIOS will set before OS
handoff.
Package TDP Lock Enable (Disabled)
Use this item to enable/disable Package TDP Lock Enable.
Power Limit 1 Time (Second) (8)
Use this item to set Power Limit 1 Time.
Power Limit 2 Switch (Enabled)
Use this item to control the Power Limit 2. This is for Turbo mode.
1/2/3/4 Core Ratio Limit (30/29/27/28)
These items show the Core Ratio limit value.
Disable OverClocking Lock (Enabled)
Use this item to control OverClocking Lock.
Runtime Turbo Enable (Disabled)
CPU Ratio (20)
This item allows users to control non turbo CPU ratio.
Long Duration Power Limit Override (Maximum)
)
Short Duration Power Limit Override (Maximum) )
This item shows if CPU support Runtime Turbo.
Intel(R) Turbo Boost Technology will use this power limit during the Long Duration
Power Limit Time Window.
Intel(R) Turbo Boost Technology will use this power limit for a very short duration.
After that, the Long Duration Power Limit will be honored.
