Chapter 3
B85H3-M7 USER MANUAL
53
Memory RC Version (1.6.1.2)
This item shows the information of the memory RC version.
Memory Frequency (1333 Mhz)
This item shows the information of the memory frequency.
Total Memory (4096 MB (DDR3))
This item shows the information of the total memory.
Memory Profiles (Automatic)
This item enables you to set the memory profiles. The selection of memory profiles
impacts memory sizing behavior.
Enh Interleave Support (Enabled)
This item allows you to enable or disable the Enh Interleave support.
RI Support (Enabled)
This item allows you to enable or disable the Rank Interleave support. NOTE: RI and
HORI can not be enabled at the same time.
DLL Weak Lock Support (Enabled)
This item allows you to enable or disable the DLL weak lock support.
Main Advanced Chipset M.I.B. III Boot Security Exit
Enable or disable 2xRef when
warm and Hot 2-iNC enables
2xRef when Hot.
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
tCCD Auto
tWPRE Auto
tRPRE Auto
tRDRD Auto
tRDRD_dr Auto
tRDRD_dd Auto
tRDPDEN Auto
CMD_3st Auto
tWRRD Auto
tWRRD_dr Auto
tWRRD_dd Auto
tWRWR Auto
tWRWR_dr Auto
tWRWR_dd Auto
tWRPDEN Auto
Dec_WRD Auto
Scomp Auto
TcoComp Auto
RcompDrvUp Auto
RcomDrvDown Auto
LsComp Auto
Enh Interleave Support Enabled
RI Support Enabled
DLL Weak Lock Support Enabled
Mc Lock Enabled
CMD Tri-State Enabled
Memory Scrambler Enabled
MRC Fast Boot Enabled
Memory Remap Enabled
Memory Thermal Management Enabled
DDR PowerDown and idle counter BIOS
Refresh 2x Mode Disabled

ECS B85H3-M7 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1666 MHz
System bus rate	5 GT/s
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	2
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	4
Supported storage drive interfaces	SATA II, SATA III
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111G
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC662
Certification	CE/FCC \\r ErP/EuP \\r WHQL \\r WHCK
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® B85
Audio output channels	5.1 channels
Motherboard form factor	mini ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
BIOS type	AMI
ACPI version	5.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	180 mm
Width	225 mm
