Chapter 3
B85H3-M7 USER MANUAL
56
CPU/RING/Cache/GT Adaptive Voltage Target(mV) (0)
This item allows you to adjust the CPU/RING/Cache/GT Adaptive voltage target from
0 to 2000mV.
CPU/RING/Cache/GT Voltage Mode (Adaptive)
This item allows you to set the CPU/RING/Cache/GT voltage mode.
CPU/RING/Cache/GT/UNCORE/IOA/IOD Voltage Offset(mV) (0)
This item allows you to adjust the CPU/RING/Cache/GT/UNCORE/IOA/IOD voltage
offset from -1000 to 998mV.
Offset Prefix (-/+)
This item allows you to select the offset value as positive (+) or negative (-).
SVID Control Enable (Enabled)
This item allows you to enable or disable the SVID control. If this function be dis-
abled, it will not be changed until CPU powers down.
SVID Override Voltage Target(mV) (0)
This item allows you to adjust the SVID override voltage target, up to 2500mV.
FIVR Faults Enable (Enabled)
This item allows you to enable or disable the FIVR faults.
If this function is disabled,
it will not be changed until CPU powers down.
FIVR Efficiency Enable (Enabled)
This item allows you to enable or disable the FIVR efficiency. If this function is dis-
abled, it will not be changed until CPU powers down.
Press <Esc> to return to the M.I.B. III Menu page.
