3
Introducing the Motherboard
Onboard LAN (optional)
• PCI Express base 1.1 compliant
• Integrated PHY for 10/100/1000 Mbps
• IEEE 802.3x compliant flow control support
• IEEE 802.3ab Auto-Negotiation support
• IEEE 802.3ab PHY compliance and compatibility
Audio (optional)
This motherboard may support either of the following Audio chipsets:
• 5.1 Channel High Definition Audio Codec
• Exceeds Microsoft Windows Logo Program (WLP) Requirements
• ADCs support 44.1K/48K/88.2K/96K/192KHz sample rate
• Power Support: Digital: 3.3V; Analog: 5.0V
The motherboard comes with the following expansion options:
• One PCI Express x16 slot for Graphic Interface
• Two PCI Express x1 slots
• One 32-bit PCI v2.3 compliant slot
• One IDE connector that supports two IDE devices
• Four 7-pin SATA connectors
Expansion Options
• Two PS/2 ports for mouse and keyboard
• One optional parallel port
• One optional DVI port
• One VGA port
• Four USB ports
• One LAN port
• Audio jacks for microphone, line-in and line-out
The motherboard has a full set of I/O ports and connectors:
Integrated I/O
• PCI Express base 1.1 compliant
• Integrated PHY for 10/100 Mbps
• IEEE 802.3x compliant flow control support
• IEEE 802.3ab Auto-Negotiation support
• 7.1 channel High Definition Audio Codec
• Compliant with Intel High Definition Audio Specification Rev.1.0
• Exceeds Microsoft Windows Logo Program (WLP) Requirements
• ADCs support 44.1K/48K/88.2K/96K/192KHz sample rate
• 5.1 Channel High Definition Audio Codec
• ADCs support 44.1k/48k/96kHz sample rate
• Meets Microsoft WLP 3.10 Vista premium and mobile PCs audio
requirements
• Direct Sound 3D
TM
compatible
