Using BIOS
CMOS Setup Utility - Copyright (C) 1985-2009, American Megatrends, Inc.
Smart Fan Function
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
Options
Press <Esc> to return to the Smart Fan Function page.
CPU SMART FAN Control Enabled
SMART Fan Mode Manual
CPU SMART Fan start PWM 28
SMART Fan start PWM TEMP (°C)32
DeltaT +3
SMART Fan Slope PWM value 4
CPU Fan Full Speed Offset (-) 7
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet
environment operation.
Silent: auto restricts
fan speed to make
system more quietly.
Manual: the fan adjust
depending on user’s
parameter.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan
speed,...etc.
• CPU FAN Speed
• CPU Vcore
• VDIMM
Press <Esc> to return to the main menu setting page.
CPU SMART Fan start PWM (28)
This item is used to set the start PWM value of the CPU smart fan.
SMART Fan start PWM TEMP (-) (32)
This item is used to set the start temperature of the smart fan.
Delta (+3)
This item specifies the range that controls CPU temperature and keeps it fromgoing
so high or so low when smart fan works.
SMART Fan Slope PWM value (4)
This item is used to set the Slope Select PWM of the smart fan.
CPU Fan Full Speed Offset (-) (7)
This item is used to set the CPU fan full speed offset value.
Press <Esc> to return to the PC Health Status page.
