ECS H55H-M User Manual

39
Using BIOS
ECS supports the latest PECI host technology. While using Core
TM
2 Quad or
Core
TM
2 Duo CPU which supports PECI, the original images of the BIOS
item “PC Health Status” and “Smart FAN Function” will be replaced by
PECI mode and negative number. (The max data from PECI is zero.)
Press <Esc> to return to the PC Health Status page.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
PC Health Status
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
Disabled
Enabled
Options
SMART Fan Control Disabled

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help

: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help

-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
CPU Fan Speed : 2509 RPM
CPU Vcore : 1.088 V
VDIMM : 1.824 V
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -60

ECS H55H-M Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 1156 (Socket H)
Processor manufacturer	Intel
S/PDIF out connector	Yes
Number of SATA connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
LAN controller	Atheros AR8131M
Networking features	Gigabit Ethernet
ACPI version	3.0
BIOS memory size	16 Mbit

Weight and Dimensions

Depth	200 mm
Width	244 mm
