ECS H61H-G11 Manual&Nbsp;

9
Installing the Motherboard
Checking Jumper Settings
The following illustration shows the location of the motherboard jumpers. Pin 1 is
labeled.
Jumper Settings
Jumper
Type
Description Setting (default)
CLR_CMOS
3-pin
Clear CMOS
1-2: NORMAL
2-3: CLEAR
Before clearing the
CMOS, make sure to
turn off the system.
CLR_CMOS
ME_DISABLE
3-pin
Disable ME
1-2: ME ENABLE
2-3: ME DISABLE
ME_ENABLE
1
3-pin
SELECT LCD
1-2: 21.5’’ AUO
M215HW03
1-2: 21.5’’ AUO
M215HW03
LCD_SEL1
1
LCD_SEL2
1
LCD_SEL1
LCD_SEL2
1
3-pin
2-3: 21.5’’ CPT
CLAA215FAO4
SELECT LCD
1-2: 21.5’’ CPT
CLAA215FAO4
LCD_SEL1
1
LCD_SEL2
1
LCD_SEL1
LCD_SEL2
3-pin
1-2: 21.5’’ BOE
HT215F01-100
SELECT LCD
2-3: 21.5’’ BOE
HT215F01-100
LCD_SEL1
LCD_SEL2
3-pin
2-3: 23.6’’ CMO
M236HGE-L20
SELECT LCD
2-3: 23.6’’ CMO
M236HGE-L20
LCD_SEL1
1
LCD_SEL1
LCD_SEL2
LCD_SEL1
1
LCD_SEL2
1
LCD_SEL2
1

ECS H61H-G11 Specifications

General

Brand	ECS
Model	H61H-G11
Category	Motherboard
Language	English
