4
Introducing the Motherboard
• LGA1155 socket for Intel
2
nd
/3
rd
Generation Core
TM
proces-
sors
• Supports “Hyper-Threading” technology CPU
• DMI 2.0GT/s
CPU
Specifications
• AMI BIOS with 32Mb SPI Flash ROM
• Supports Plug and Play, STR (S3)/STD (S4)
• Hardware monitor, Multi Boot
• Supports ACPI & DMI
• Audio, LAN, can be disabled in BIOS
Form Factor
• Thin Mini-ITX Size, 170mm x 170mm
System BIOS
• Intel
H61 Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 SO-DIMM sockets support up to 8 GB
• Supports 1333/1066 DDR3 SO-DIMM
• 1 x Mini PCI Express slot (supports half-card)
• Supported by Intel
H61 Express Chipset
- SATA * 2 3.0 Gb/s devices
• Realtek ALC662GR 5-Ch High Definition audio CODEC
• 4 x USB 2.0 ports
• 1 x DC-IN port
• 1 x HDMI port
• 1 x RJ45 LAN connector
• 2 x Audio port (microphone in, line out)
Memory
Expansion Slot
Storage
LAN
Rear Panel I/O
• Realtek 8111E Giga Lan
Audio
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x Front panel audio header
• 1 x Front panel switch/LED header
• 1 x Speaker header
• 2 x Serial SATA 3.0 Gb/s connectors
• 1 x USB 2.0 header support additional two USB 2.0 ports
• 1 x Clear CMOS header
• 1 x LVDS connector
• 1 x Inverter/converter
• 1 x ME_UNLOCK header
Internal I/O
Connectors &
Headers
