17
Installing the Motherboard
ODD_PW: ODD power connector
This connector is used to provide power for the 0DD.
1 +5V
2 +5V
3 GND
Pin Signal Name
TS: Touch board header
1 +5V
2 USB_N
3 USB_P
Pin Signal Name
4 GND
5 Key
CAMERA: CCD header
1 +5V
2 USB_N
3 USB_P
Pin Signal Name
4 GND
5 Key
MCR: Card reader header
1 +5V
2 USB_N
3 USB_P
Pin Signal Name
4 GND
5 Key
LCD_OFF: Panel switch
This connector is used to provide power for the 0DD.
1 PWRDN
2 GND
Pin Signal Name
