Chapter 3
H61H2-I3 USER MANUAL
51
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B III (MB Intelligent BIOS III) Menu
Integrated Clock Chip
Parameters
F1:General Help
+/- : Change Opt.
Enter : Select
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
M.I.B III (MB Intelligent BIOS III)
CPU OverClocking Configuration
Chipset OverClocking Configuration
B.O.M.P Technology [Enabled]
Auto Detect DIMM/PCI Clk [Enabled]
Spread Spectrum [Enabled]
Intel(R) Core(TM) i7-3770K CPU @ 3.50GHz
Processor Speed 3500 MHz
Memory Frequency 1333 MHz
Total Memory 8192 MB (DDR3)
CPU OverClocking Configuration
Scroll to this item to view the following screen:
CPU OverClocking Configuration
CPU Frequency 100
CPU Ratio 35
Enhanced Intel SpeedStep Technology [Enabled]
Turbo Mode [Enabled]
Internal PLL OverVoltage [Disabled]
Runtime Turbo Enable [Disabled]
Over Clocking Extra Vol.(1/256 V) 0
IA Core Current Maximum
iGFX Core Current Maximum
Long Duration Power Limit Override Maximum
Long Duration Maintained 10
Short Duration Power Limit Override Maximum
Intel Graphics Configuration
Graphics Core Ratio Limit 23
Graphics Voltage(1/256) 0
Enhanced Intel SpeedStep
Technology
