English
45
Step1. Ins of the CPU and CPU Cooler:
Hardware Guide
Steps
1-1. Pull up the lever away from the
socket.
Step2. of Memory Modules:
2-1. Unfasten the latches on each side
of the DIMM slots.
Step3. of Motherboard:
3-1. Replace the back I/O plate of the
case with the I/O shield provided in
motherboard’s package.
1-2. Align the CPU cut edge with the
indented edge of the CPU socket. Gently
place the CPU into correct posi
on.
Apply an even layer of thermal grease
on the surface of CPU.
1-3. Rotate and press down the
fastener of CPU fan to the motherboard
through holes to install CPU fan into
place.
1-4. Connect the CPU cooler power
connectortotheCPU_FANconnector.
2-2. Firmly press the DIMM down un
lit
seats correctly. Make sure the slot
latches are levered upwards and latch
on the edge of the DIMM.
3-2. Place the motherboard within the
case by
it into the I/O plate.
Secure the motherboard to the case
with screws.
To Next Page
