31
Using BIOS
• CPU Fan Speed
• CPU Voltage
• IMC Voltage
• DIMM Voltage
• VAXG Voltage
System Component Characteristics
These items display the monitoring of the overall inboard hardware health
events, such as CPU & DIMM voltage, CPU fan speed...etc.
Press <Esc> to return to the Advanced Menu page.
SMART Fan start PWM value (180)
SMART Fan start TEMP(-) (30)
This item is used to set the start PWM value of the smart fan.
This item is used to set the start temperature of the smart fan.
DeltaT (+3)
This item specifies the range that controls CPU temperature and keeps it from going
so high or so low when smart fan works.
SMART Fan Slope PWM value (10 PWM value/unit)
This item is used to set the Slope Select PWM of the smart fan.
This item is used to set the CPU fan full speed offset value.
CPU Fan Full Speed Offset(-) (23)
Press <Esc> to return to the PC Health Status page.
