ECS H61H2-M13 User Manual

50
Using BIOS
IA Core Current
CPU Ratio 34
IA Core Current [Normal]
Power Limit 1 Value (Watt) 95
Power Limit 2 Switch [Enabled]
Power Limit 2 Value 118
Long duration Maintained 1
Enhanced Intel SpeedStep Technology [Enabled]
Turbo Mode [Enabled]
1 Core Ratio Limit 38
2 Core Ratio Limit 37
3 Core Ratio Limit 36
4 Core Ratio Limit 35
f Performance Tunning
Scroll to this item to view the following screen:
fCPU Configuration
Scroll to this item to view the following screen:
CPU Configuration
Performance Tuning
CPU Configuration
Chipset Configuration
f
f
Power Limit 2 Switch (Enabled)
Use this item to control the Power Limit 2. This is for Turbo mode.
Power Limit 1 Value(Watt) (95)
Use this item to control the limit of the TDP. This is for Turbo mode.
CPU Ratio (34)
This item allows users to control non turbo CPU ratio.
IA Core Current (Normal)
Use this item to control CPU Current Limit. This is for Turbo mode.
F2:Previous Values
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
F2:Previous Values
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
