52
Using BIOS
RAS# to CAS# Delay(tRD) (7)
This item specifies the RAS# to CAS# delay to Rd/Wr command to the same bank.
RAS# Active Time(tRAS) (20)
This item specifies the RAS# active time.
GT OverClocking (Disabled)
This item allows you to control the internal GFX Turbo mode.
Press <Esc> to return to the Performance Tunning page.
Press <Esc> to return to the M.I.B III Menu page.
Row Precharge Time(tRP) (7)
This item specifies Row precharge to Active or Auto-Refresh of the same bank.
Memory Timing Configuration
This item shows the information of Memory Timing Configuration.
CAS# Latency(tcl) (7)
This item determines the operation of DDR SDRAM memory CAS (column address
strobe). It is recommended that you leave this item at the default value. The 2T
setting requires faster memory that specifically supports this mode.
Intel Graphics Configuration
This item shows the information of Intel Graphics Configutation.
Memory Multiplier (10.67)
This item shows the information of Memory Multiplier.
Write Recovery Time(tWR) (8)
This item specifies the write recovery time.
Row Refresh Cycle Time(tRFC) (59)
This item specifies the row refresh cycle time.
Write to Read Delay(tWTR) (4)
This item specifies the write to read delay time.
Active to Active Delay(tRRD) (4)
This item controls the ACTIVE bank x to ACTIVE bank y delay in memory clock
cycles.
Read CAS# Precharge(tRTP) (4)
This item controls the Read to PRECHARGE delay for memory devices, in memory
clock cycles.
Four Active Window Delay(tFAW)(20)
This item controls the four bank activate time in memory clock cycles.
