ECS H67H2-M v 1.1 User Manual

5
Introducing the Motherboard
• AMI BIOS with 32Mb SPI Flash ROM
• Supports Plug and Play, STR (S3)/STD (S4), Hardware moni-
tor, Multi Boot
• Supports ACPI & DMI
• Audio, LAN, can be disabled in BIOS
• F7 hot key for boot up devices option
• Supports PgUP clear COMS Hotkey
• Supports ACPI 3.0 revision
• Supports eJIFFY, eBLU, eDLU, eSF
• Supports Graphic Over-Clocking
• Supports Multi-Monitor technology
• Supports Intel Turbo Boost
• Supports ECS M.I.B III Utility
-CPU Voltage Adjustable
-Memory Voltage Adjustable
-IMC Voltage Adjustable
-Graphic Voltage Adjustable
Form Factor
• Micro ATX Size, 244mm x 244mm
• 1 x Onboard Buzzer
• 1 x Reset button
• 1 x Power on button
• 1 x SPDIF out header
• 1 x Clear CMOS header
System BIOS
• 1 x 24-pin ATX Power Supply connector
• 1 x 8-pin 12V connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin PWR_FAN connector
• 1 x 4-pin SYS_FAN connector
• 3 x Serial SATA 3.0 Gb/s connectors
• 2 x Serial SATA 6.0 Gb/s connectors
• 1 x Front panel switch/LED header
• 1 x Front panel audio header
• 4 x USB 2.0 headers support additional 8 USB 2.0 ports
(F_USB 1 supports EZ charger)
• 1 x TPM header
• 1 x Chassis instrusion header
Internal I/O
Connectors &
Headers
