Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
latest LGA1155 socket for Intel
®
2
nd
Generation Core
TM
i7, i5, i3, Pentium & Celeron processors
2. CPU_FAN CPU cooling fan connector
3. DDR3_1~4 240-pin DDR3 SDRAM slots
4. PWR_FAN Power cooling fan connector
5. ATX_POWER Standard 24-pin ATX power connector
6. SATA1~5 Serial ATA connectors
7. F_PANEL Front panel switch/LED header
8. BZ Buzzer
9. RST_BTN Reset button
10. PWR_BTN Power on button
Front panel USB headers (F_USB1 Gray one is for
EZ Charger)
12. CASE CASE open header
13. ME_UNLOCK ME unlock header-for factory use only
14. TPM Trusted Platform Module header
15. CLR_CMOS Clear CMOS jumper
16. SYS_FAN System cooling fan connector
17. SPDIFO SPDIF out header
18. F_AUDIO Front panel audio header
19. PCI 32-bit add-on card slot
20. PCIE1~2 PCI Express x1 slots
21. PCIEX16 PCI Express slot for graphics interface
22. ATX12V 8-pin +12V power connector
1. CPU Socket
11. F_USB1~4
