25
Installing the Motherboard
ATX12V: ATX 12V Power Connector
Pin Signal Name
4 +12V
3 +12V
2 Ground
1 Ground
SPK: Internal speaker
Pin Signal Name
1 VCC
2 Key
3 GND
4 Signal
