ECS H81H3-M4 User Manual

H81H3-M4 USER MANUAL
1
Brief Introduction
CPU
Specifications
• Intel
®
H81 ChipsetChipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1600/1333 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x16 Gen2 slot
• 1 x PCI Express x1 slot
• Supported by Intel
®
H81 Express Chipset
- 2 x Serial ATA 6Gb/s devices, 2 x Serial ATA 3Gb/s devices
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x HDMI port
• 1 x VGA port
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 2.0 ports
• 1 x Audio port (1x Line in, 1x Line out, 1x Mic_in Rear)
Rear Panel I/O
• Realtek RTL8111G Giga LAN(Colay 10/100)
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• LGA1150 socket for 4
th
Generation Intel
®
Core
TM
Family/
Pentium/Celeron Processors
Note: Please go to ECS website for the latest CPU support list.
• 1 x 24-pin ATX_Power Supply connector
• 1 x 4-pin ATX12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 2 x Serial SATA 6Gb/s connectors
• 2 x Serial SATA 3Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x Front panel USB power select jumper
• 1 x LDC header
• 1 x Front Panel audio header
• 1 x Speaker header
• 1 x ME_UNLOCK header
• 1 x CLR_CMOS jumper
Internal I/O
Connectors &
Headers
• VIA VT1705
-
6 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
LAN

ECS H81H3-M4 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H81
CPU Socket	LGA 1150
Memory Slots	2 x DIMM
Maximum Memory	16 GB
Memory Type	DDR3
Audio	Realtek ALC662 6-Channel HD Audio
Storage Interface	2 x SATA 3Gb/s
USB Ports	2 x USB 3.0, 6 x USB 2.0
Video Outputs	1 x VGA
LAN	Realtek RTL8111G
Power Connector	24-Pin ATX Power Connector, 4-Pin ATX 12V Power Connector
Expansion Slots	1 x PCIe 2.0 x16, 1 x PCIe 2.0 x1
