27
Chapter 3: BIOS Setup Utility
Share Memory Size (Enabled, 8MB)
This item lets you allocate a portion of the main memory for the onboard VGA display
application.
Press <Esc> to return to the main menu setting page.
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Enabled
Onboard SATA Controller Enabled
USB Functions Enabled
Legacy USB Support Enabled
Audio Controller Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8&IRQ4
Disable / Enable the
integrated IDE
Controller.
Help Item
mnlk
: Move Enter : Select
+/-/: Value
F9: Optimized Defaults ESC: Exit
F1: General Help
F10: Save and Exit
Onboard IDE Controller (Enabled)
Use this item to enable or disable the onboard IDE interface.
Onboard SATA Controller (Enabled)
Use this item to enable or disable the onboard SATA controller.
USB Functions (Enabled)
Use this item to enable or disable the USB function.
Parallel Port Address 378
Parallel Port Mode ECP
ECP Mode DMA Channel DMA3
Parallel Port IRQ IRQ7
Legacy USB Support (Enabled)
Use this item to enable or disable support for legacy USB devices. Setting to Auto
allows the system to detect the presence of USB device at startup. If detected, the USB
controller legacy mode is enabled. If no USB device is detected, the legacy USB support
is disabled.
Audio Controller (Enabled)
Use this item to enable or disable the onboard audio controller.
OnBoard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
OnBoard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network add-
in card with a remote boot ROM installed.
To Next Page
