Parallel Port Address (378)
Use this item to enable or disable the onboard Parallel port, and to assign a port address.
Parallel Port Mode (ECP)
Use this item to select the parallel port mode. You can selet Normal (Standard Parallel
Port), ECP (Extended Capabilities Port), EPP (Enhanced Parallel Port), or BPP (Bi-
Directional Parallel Port).
ECP Mode DMA Channel (DMA3)
Use this item to assign the DMA Channel under ECP Mode function.
Parallel Port IRQ (IRQ7)
Use this item to assign IRQ to the parallel port.
Serial Port1 Address (3F8&IRQ4)
Use this item to enable or disable the onboard COM1/2 serial port, and to assign a port
address.
Power Management Setup
This page sets up some parameters for system power management operation.
Select the ACPI
state used for
System Suspend.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Power Management Setup
*ACPI Suspend Mode S3 (STR)
Soft-off by PWR-BTTN Delay 4 Sec
PWRON After PWR-Fail Power Off
Resume On LAN Disabled
Wake-Up by PME Enabled
Power On by Ring Disabled
USB KB Wakeup From S3 Disabled
PS2 Keyboard Wakeup Disabled
PS2 Mouse Wakeup Disabled
Resume on RTC Alarm Disabled
mnlk
: Move Enter : Select
+/-/: Value
F9: Optimized Defaults ESC: Exit
F1: General Help
F10: Save and Exit
*ACPI Suspend Mode (S3(STR))
Use this item to define how your system suspends. In the default, S3, the suspend mode
is a suspend to RAM, i.e, the system shuts down with the exception of a refresh current
to the system memory.This item will not show when the FSB reaches 1333MHz.
Soft-Off By PWR-BTTN (Delay 4 Sec)
Under ACPI (Advanced Configuration and Power management Interface) you can
create a software power down. In a software power down, the system can be resumed by
Wake Up Alarms. This item lets you install a software power down that is controlled by
the power button on your system. If the item is set to Instant-Off, then the power
button causes a software power down. If the item is set to Delay 4 Sec, then you have
to hold the power button down for four seconds to cause a software power down.
Press <Esc> to return to the main menu setting page.
