Chapter 3
Q87H3-M5 USER MANUAL
47
Parallel Port Configuration
Parallel Port [Enabled]
Device Settings IO=378h; IRQ=5; DMA=3;
Change Settings [Auto]
Device Mode [ECP Mode]
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Enable or Disable Parallel Port
(LPT/LPTE)
Advanced
F1:General Help
+/- : Change Opt.
Enter : Select
lk
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Parallel Port Configuration
Scroll to this item and press <Enter> to view the following screen:
f
Parallel Port (Enabled)
This item allows you to enable or disable parallel port.
Press <Esc> to return to the Advanced Menu page.
Press <Esc> to return to the Super IO Configuration page.
Device Settings (IO=378h; IRQ=5; DMA=3;)
This item shows the information of the device settings.
Change Settings (Auto)
Use this item change device settings.
Device Mode (ECP Mode)
This item shows the information of the device mode.
