Q87H3-M5 USER MANUAL
Chapter 4
Chapter 4
Intel
®
Matrix Storage Manager RAID Configuration
The Intel
®
Matrix Storage Manager allows you to configure RAID 0, and 1 sets on the
external Serial ATA hard disk drives.
1. Install the external Serial ATA hard disk drive (HDD) on your system.
2. Set the SATA Mode item in the BIOS from “IDE Mode” to “RAID Mode”
See section “SATA Configuration” for details.
Before creating a RAID set
1. One SATA HDD.
2. A write-enabled floppy disk.
3. Microsoft
®
Windows
®
OS installation disk (Windows XP/7/8).
4. Motherboard support CD with Intel
®
Matrix Storage Manager driver.
Complete the following steps before you create a RAID set:
Prepare the following items:
Version 2.15.1236. Copyright (C) 2002-2013 American Megatrends, Inc.
BIOS Setup Utility
SATA Configuration
SATA Mode [AHCI Mode]
SATA Port 1
Not Present
Spin Up Device [Disabled]
External SATA [Disabled]
SATA Port 2
Not Present
Spin Up Device [Disabled]
External SATA [Disabled]
SATA Port 3
Not Present
Spin Up Device [Disabled]
External SATA [Disabled]
SATA Port 4
Not Present
Spin Up Device [Disabled]
External SATA [Disabled]
SATA Port 5
Not Present
Spin Up Device [Disabled]
External SATA [Disabled]
Determines how SATA controllers
operate.
Advanced
mn
lk
+/-/Spacebar : Change Opt.
Enter : Select
F1: General Help
:Move
F2: Previous Values
F3: Optimized Defaults
F4: Save and Exit
ESC: Discard changes and Exit
Setup
Version 2.15.1236. Copyright (C) 2002-2013 American Megatrends, Inc.
