Chapter 3
Q87H3-M5 USER MANUAL
61
Memory Configuration
Scroll to this item to view the following screen:
Memory RC Version (1.8.0.0)
This item shows the information of the memory RC version.
Memory Frequency (1333 Mhz)
This item shows the information of the memory frequency.
Total Memory (2048 MB (DDR3))
This item shows the information of the total memory.
Memory Profiles (Automatic)
This item enables you to set the memory profiles.
The selection of memory profiles
impacts memory sizing behavior.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Memory Information
Memory RC Version 1.8.0.0
Memory Frequency 1333 MHz
Tatal Memory 2048 MB (DDR3)
Memory Profiles [Automatic]
Memory Frequency [1333]
Timing Default Current Target
tCL 9 9 9
tRCD 9 9 9
tRP 9 9 9
tRAS 24 24 24
NMode 1 1 Auto
tWR 10 10 10
tRFC 74 74 74
tRRD 7 7 7
tWTR 5 5 5
tRTP 5 5 5
tCWL 7 7 7
tREFI 5200 5200 5200
tFAW 20 20 20
tWRPRE Auto
tCPDED Auto
M.I.B.X
lk
F1:General Help
+/- : Change Opt.
Enter : Select
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
The Selection of Memory
Profiles which impacts memory
sizing behavior
f
To Next Page
