CPU/RING/Cache/GT Adaptive Voltage Target(mV) (0)
This item allows you to adjust the CPU/RING/Cache/GT Adaptive voltage target from
0 to 2000mV.
CPU/RING/Cache/GT Voltage Mode (Adaptive)
This item allows you to set the CPU/RING/Cache/GT voltage mode.
CPU/RING/Cache/GT/UNCORE/IOA/IOD Voltage Offset(mV) (0)
This item allows you to adjust the CPU/RING/Cache/GT/UNCORE/IOA/IOD voltage
offset from -1000 to 998mV.
ChReadVref 0.752 V (Auto)
This item allows you to adjust the ChReadVref from 0 to 108, and the default is 54,
1 step is 4mV.
Over Voltage Configuration
Scroll to this item to view the following screen:
Ch0WriteVref 0.736 V (Auto)
This item allows you to adjust the Ch0WriteVref from 0 to 108, and the default is 54,
1 step is 4mV.
Ch1WriteVref 0.752 V (Auto)
This item allows you to adjust the Ch1WriteVref from 0 to 108, and the default is 54,
1 step is 4mV.
ChVrefCA 0.752 V (Auto)
This item allows you to adjust the ChVrefCA from 0 to 108, and the default is 54, 1
step is 4mV.
