Chapter 1
2
Q87H3-M6
USER MANUAL
CPU
Specifications
• Intel
®
Q87 Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 32 GB
• Supports DDR3 1600/1333 MHz
Memory
• 1 x PCI Express x16 Gen3 slot
• 1 x PCI Express x16 Gen2(with x4 connectivity) slot
• 1 x PCI Express x1 slot
• 1 x PCI slot
• Supported by Intel
®
Q87 Express Chipset
- 5 x Serial ATA 6.0 Gb/s devices
- RAID 0, RAID 1, RAID 5, RAID 10 Configuration
Expansion
Slots
Storage
• 1 x PS/2 keyboard & PS/2 mouse connectors
• 1 x Display port(DP)
• 1 x HDMI port
• 1 x D-sub port(VGA)
• 1 x DVI port
• 4 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 2.0 ports
• 1 x Audio port (Line in, line out and microphone)
Rear Panel I/O
LAN • Intel
®
WGI217LM
• Realtek ALC662 6-Ch HD audio CODEC
Audio
• LGA1150 socket for
Intel 4
th
Generation Core
TM
Family
processors
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX_12V Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 5 x SATA III 6.0Gb/s connectors
• 1 x Front panel switch/LED header
• 1 x Front panel audio header
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 1 x 5-pin USB 2.0 header supports additional one USB 2.0 port
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 2 x Onboard Serial port headers (COM)
• 1 x Clear CMOS header with jumper
• 1 x Onboard parallel port header (LPT)
• 1 x Buzzer
• 1 x Case open header
Internal I/O
Connectors &
Headers
