33
Using BIOS
SMART Fan start PWM value (28)
This item is used to set the start PWM value of the CPU smart fan.
CPU DeltaT (+3)
This item specifies the range that controls CPU temperature and keeps it fromgoing
so high or so low when smart fan works.
SMART Fan Slope PWM value (5 PWM value/°C )
This item is used to set the Slope Select PWM of the smart fan.
CPU FAN Full Limit Temp (-) (63°C)
This item is used to set the limit temperature of the smart fan.
Press <Esc> to return to the PC Health Status page.
SMART Fan start TEMP. (°C ) (43)
This item is used to set the start temperature of the smart fan.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as CPU temperature, CPU fan speed, System Fan Temperture...etc.
CPU Temperature
System Fan Speed
CPU Fan Speed
• CPU Vcore
• VDIMM
Press <Esc> to return to the main menu setting page.
