SATA Configuration
Use this item to show the mode of serial SATA configuration options.
Press <Esc> to return to the Advanced Menu page.
SATA Mode (IDE Mode)
Use this item to select SATA mode.
SATA Port 2~6 (Not Present)
This motherboard supports six SATA channels and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel.
Determines how SATA
controller(s) operate.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
SATA Configuration
SATA Mode IDE Mode
SATA Port1 ST3120827AS (120.0G
SATA Port2 Not Present
SATA Port3 Not Present
SATA Port4 Not Present
Press <Esc> to return to the SATA Configuration page.
SATA Port5 Not Present
SATA Por6 Not Present
SATA Port 1 [ST3120827AS (120.0G ]
This item shows the information of device installed in the port.
