③Mini Report
The left side of the screen displays a “mini-report” which displays measurements performed during the
current exam.
④Thumbnail Field
The right side of the screen displays thumbnail images of all statics and clips captured for currently
active exam or when in Review. This field also contains several shortcut keys for selecting, viewing,
deleting, exporting images. See the below for details:
No.
Shortcut Keys
Description
1
Select All
Selects all the displayed static images and clips.
2
Delete
Deletes the selected static images and clips.
3
Export
Exports the selected static images and clips to removable
storage devices.
4
Page Up
Turns the page up when more than one page of images are
displayed.
5
Page Down
Turns the page down when more than one page of images
are displayed.
⑤ Soft Keys Field
The soft keys filed is displayed below image field and above status bar. This field displays:
 The illustration of trackball and trackball keys.
 Cine bar when the system is frozen.
 An "Exit" icon . Only displayed in review mode. Clicking on this icon will exit the review
mode.
⑥ Status Bar
The bottom of the screen is used to display icons that provide system status. These include:
No.
Icons
Description
1
Utility icon
Provides access to system setup, screen adjust,
connectivity, maintenance, etc.
2
Image Store
icon
Displays the number of static images and clips stored in the
current exam.
3
USB icon
USB disk available.
4
Printer icon
Printer available.
Symbol is in green when printing in progress.
