Patient Monitor User Manual Product Specification
- 283 -
Note 3: Interference at indicated gas level. For example, 50 vol% Helium typically decreases the
CO
2
readings by 6%. This means that if measuring on a mixture containing 5.0 vol% CO
2
and 50
vol% Helium, the measured CO
2
concentration will typically be (1-0.06) * 5.0 vol% = 4.7 vol%
CO
2
.
Note 4: According to the EN ISO 80601-2-55:2011 standard.
Note 5: In addition to the EN ISO 80601-2-55:2011 standard.
A.15 Interfaces
A.15.1 Analog Output
Bandwidth (-3 dB; reference
frequency: 10 Hz)
Monitor: 0.5 Hz to 40 Hz
Diagnosis: 0.5 Hz to 40 Hz
Diagnosis 1: 0.05 Hz to 40 Hz
Surgery: 1 Hz to 20 Hz
Enhanced: 2 Hz ~18 Hz
Customized: When Low-pass Filter < 40 Hz, Bandwidth is
High-pass Filter ~ Low-pass Filter; When Low-pass Filter >
40 Hz, Bandwidth is High-pass ~40 Hz.
Maximum Transmission Delay
(Diagnosis Mode)
500 ms
Sensitivity 1 V/1 mV ±10%
PACE Rejection/ Enhancement No PACE rejection or enhancement
Waveform Display Consistent with the calculation leads.
Compliant with Standard and
Directive
Complies with the requirements in terms of short circuit
protection and leakage current in EN60601-1.
Output Impedance < 500 Ω
Interface Type PS2 connector
NOTE:
While using analog output, set the calculation lead as following:
1) In 3 Electrodes mode, set to Lead I, Lead II, or Lead III.
2) In 5 Electrodes mode, set to Lead I, Lead II, Lead III or Lead V.
3) In 6 Electrodes mode, set to I, II, III, and leads corresponding to Va, Vb.
4) In 10 Electrodes mode, set to Lead I, Lead II, Lead III or Lead V1~V6.
