HD-KL18-0623
Page 17
PARTS LISTING - ILLUSTRATION 1: MAIN GROUPING
ITEM # PART # DESCRIPTION QTY.
1 100008HD MAIN FRAME WELDMENT, KL18 1
2 10009 WASHER, FLAT 3/4 SAE ZINC 6
3 79013 WHEEL, 8 X 2-1/2 X 3/4”BRG.POLY HUB 2
4 10306 PIN, COTTER 3/16 X 1-1/2 2
5 100005HD FORK WELDMENT, KL18 1
6 10009 WASHER, FLAT 3/4 SAE ZINC 4
7 54026 WHEEL, 4 X 2 X 3/4 W/ ROLLER BRG. 2
8 10306 PIN, COTTER 3/16 X 1-1/2 2
9 65239 SCREW, CAP 1/2-13 X 10 1
10 10312 WASHER, FLAT 1/2 SAE ZINC 2
11 10155 NUT, HEX NYLON LOCK 1/2-13 ZINC 1
12 10347 SCREW, CAP 1/2-20 X 2-1/4 1
13 10154 NUT, HEX NYLON LOCK 1/2-20 ZINC 1
14 100006HD LINKAGE WELDMENT, KL18 1
15 100007HD HANDLEBAR WELDMENT, KL18 1
16 10608 GRIP, HAND 1” MODEL AT 2
17 80008 HANDWHEEL, SMALL W/ 5/8-11 X 12”ROD 1
18 14023 KNOB, BALL 1-3/8 W/ 1/2-13THD, BLK. 1
19 50550 SLEEVE, BRASS 1/2” TAPERED 1
20 10411 SCREW, SKT. HD. CAP 1/2-13 X 4 ZINC 1
21 80009 BEARING, BALL 5/8” 2-HOLE (NO G.F.) 1
22 10412 BOLT, CARRIAGE 1/4-20 X 1 2
23 10602 WASHER, FLAT 1/4 SAE ZINC 2
24 10150 NUT, HEX NYLON LOCK 1/4-20 ZINC 2
25 55010 SPACER, HANDWHEEL 5/8”ID X 3/4”L 1
26 10046 NUT, HEX 5/8-11 ZINC 1
27 10317 SCREW, CAP 3/8-16 X 2 4
28 10025 WASHER, FLAT 3/8 SAE ZINC 8
29 10156 NUT, HEX NYLON LOCK 3/8-16 ZINC 4
30 100003HD BELT GUARD WELDMENT, KL18 1
31 10907 SCREW, CAP 3/8-16 X 3/4 2
32 10811 WASHER, LOCK 3/8 ZINC 4
33 10025 WASHER, FLAT 3/8 SAE ZINC 4
34 100004HD LIFTING BAIL WELDMENT, KL18 1
35 10055 SCREW, CAP 3/8-16 X 1 3
36 10025 WASHER, FLAT 3/8 SAE ZINC 6
37 10156 NUT, HEX NYLON LOCK 3/8-16 ZINC 3
38 100001HD GUIDE BAR WELDMENT, KL18 1
39 50024 WHEEL 4 X 1-3/8 X 3/8”BORE 1
40 11669 SCREW, CAP 3/8-16 X 2-1/2 1
41 10025 WASHER, FLAT 3/8 SAE ZINC 2
42 10156 NUT, HEX NYLON LOCK 3/8-16 ZINC 1
43 10055 SCREW, CAP 3/8-16 X 1 1
44 10025 WASHER, FLAT 3/8 SAE ZINC 1
45 10156 NUT, HEX NYLON LOCK 3/8-16 ZINC 1
