Edco 39600HD - Page 19

HD-KL18-0623
Page 19
PARTS LISTING - ILLUSTRATION 2:
ARBOR & BLADE GUARD GROUPING
ITEM # PART # DESCRIPTION QTY.
1 100213 ARBOR ASSY. COMPLETE, KL-18
(INCLUDES ITEMS 2 THRU 13)
1
2 69050 ARBOR SHAFT 19-1/4”L 1
3 50222 BEARING, BALL 1” TPB 2
4 10960 FITTING, GREASE 1/4-28 X 45° 2
5 10808 FITTING, GREASE 1/4-28 STRAIGHT 2
6 56308 ARBOR BACKING PLATE 4-1/2”, DS-18 1
7 10211 PIN, ROLL 5/16 X 2 1
8 56309 ARBOR BLADE CAP 4-1/2”
(INCLUDES ITEM 9
1
9 10129 PIN, SHEAR PROOF 3/8 X 1-1/4 1
10 55009 WASHER, LOCK, INT. TOOTH 1” 1
11 50020 NUT, HEX JAM 1-14 ZINC GRADE 8 1
12 10115 KEY 1/4SQ X 2 1
13 56235 SHEAVE 3.35”OD X 3GR.3V X 1”BORE 1
14 10907 SCREW, CAP 3/8-16 X 3/4 4
15 10811 WASHER, LOCK 3/8 ZINC 4
16 50445 WRENCH, ARBOR, 1-1/2” OPEN END 2
17 300037HD BLADE GUARD ASSEMBLY, KL-18
(INCLUDES ITEMS 18, 19 & 20)
1
18 100002HD BLADE GUARD WELDMENT, KL18 1
19 11881 NOZZLE, FLAT SPRAY 1/8 NPT MALE 1
20 11562 BARB ELBOW 90, 3/8HOSE X 1/8MPT 1
21 49016 PIN, DETENT RING 1/4 X 1 E.L. 2
22 10711A VALVE & HOSE CONNECTOR ASSY. 1
23 56022 BRACKET, WATER VALVE 1
24 10038 WASHER, LOCK 1/4 ZINC 2
25 10846 SCREW, CAP STSHW 1/4-20 X 5/8 2
26 10799 BARB ELBOW 90, 3/8HOSE X 1/4MPT 1
27 10714 CLAMP, HOSE, SAE #4, ADJ. TO 5/8” 2
28 56317 HOSE, WATER 3/8”ID X 48”L 1
29 10982 TIE, CABLE, BLACK NYLON 12” 1
30 HG1812V3 DIAM.BLADE 18” X .125 X 1” 1
