Edco 39600HD - Page 21

HD-KL18-0623
Page 21
PARTS LISTING - ILLUSTRATION 3: ENGINE GROUPING
ITEM # PART # DESCRIPTION QTY.
1 15029
15504
ENGINE, HONDA GX390UT2QC9 (SHOWN)
ENGINE, KOHLER CH440 (NOT SHOWN)
1
1
2 10625 MUFFLER CAP, HONDA #18331-ZE3-811 1
3 10128 RIVET, BLIND 1/8 X .275L X .250HD 2
4 56234 OIL DRAIN KIT 1
5 100221
101221
LEVER CONTROL ASSY., THROTTLE (HONDA)
THROTTLE CABLE, LOCKING 49” (KOHLER)
1
1
6 100222 LEVER CONTROL, KNOB 1
7 11811 BOLT, FLANGE 1/4-20 X 3/4 ZINC 2
8 10150 NUT, HEX NYLON LOCK 1/4-20 ZINC 2
9 15201A SWITCH W/ WIRES, ROCKER RED ON-OFF 1
10 10970 CONN., WIRE QUICK-SPLICE 18-14 GA. 1
11 10976 TERM., RING 3/8 12-10GA. INS. (HONDA) 1
12 36042 ADHESIVE CORD CLIP 5/8”SQ. 2
13 10364
10087
BOLT, CARRIAGE 3/8-16 X 2 GRADE 5
BOLT, CARRIAGE 3/8-16 X 1-3/4
1
3
14 10025 WASHER, FLAT 3/8 SAE ZINC 4
15 10811 WASHER, LOCK 3/8 ZINC 4
16 10404 NUT, HEX 3/8-16 ZINC 5
17 10453 WASHER, LOCK, INT. TOOTH 3/8” 1
18 10868 SCREW, CAP 3/8-16 X 3-1/2 1
19 10404 NUT, HEX 3/8-16 ZINC 1
20 10307 KEY 1/4SQ X 2-1/4 1
21 65238 SHEAVE 2.8”OD X 3GR.3V X 1”BORE 1
22 10273 BELT 3VX-300 3
23 10941 CLIP, CONDUIT, THROTTLE CABLE (KOHLER) 1
24 10831 WASHER, LOCK, INT. TOOTH #10 1
25 10877 SCREW, CAP STSHW 10-24 X 1/2 1
26 10452 WASHER, LOCK, INT. TOOTH 5/16” 1
27 10986 TERM., RING 5/16 16-14GA. INS. (KOHLER) 1
28 10053 SCREW, CAP 5/16-18 X 3/4 1
