Page #27 background imageLoading...
Page #27 background image
27
I N S T R U M E N T
Size 400,5 mm x 273mm x 131,5mm
Weight (g)
6,4 Kg with 1 battery
14.1 lbs
Power supply
DC - 15V / 5,67A / 85 VA
AC - 100V-240V / 105VA
Battery
2 Li-Ion batteries, 94 Wh
Up to 6h with 2 batteries
(hot swap capabilities)
Display
Size 26cm (10,4’)
Brightness 800 cd/m2
Resolution 1024x768
Contrast 900:1
Resistive touch screen
Storage 256 GB SSD, expandable up to 1TB
14. TECHNICAL SPECIFICATIONS
* Depends on the hardware configuration (32:128PR, 64:64PR or 64:128PR).
E N V I R O N M E N T
IP rating Designed for IP66
Operating
temperature
-10 to 45°C (14 to 113°F)
Storage
temperature
w/ batteries -20 to 60°C (-4 to 140°F)
w/o batteries -20 to 70°C (-4 to 158°F)
Drop-tested According to MIL-STD-810G
C O N N E C T I V I T Y
Phased-Array IPEX (x1)
UT-TOFD
LEMO-00 (x4)
x4 P/R or x2 P/C
Encoder Input*
LEMO16 connector
Up to 3
TTL
Quadrature or clock/dir
4MHz max
Synchro Input Output* 2 TTL inputs
USB
USB 3.0 (×1)
USB 2.0 (×3)
Display Micro display port (x1)
AV A I L A B L E
C O N F I G U R AT I O N S
Without TFM
32:128PR
64:64PR
64:128PR
With TFM
32:128PR-TFM32
32:128PR-TFM64
64:64PR-TFM64
64:128PR-TFM64
64:128PR-TFM128
