14. TECHNICAL SPECIFICATIONS
P h a s e d - A r r a y
P u l s e r
Number of channels
Up to 128*
Pulse type
Bipolar square pulse
Amplitude From 12 to 120 V (1V) – No
load (in Capture software)
From 10 to 100 V (1V) – Load
50 ohms
Pulse width Pulse width from 30 to 1250 ns
False time < 6ns
R e c e i v e r
Number of channels Up to 128*
Up to 64* active channels,
simultaneously
Input impedance
50Ω
Frequency range
Frequency range 0.4 to 20 MHz
Max. input signal
2 Vpp
Gain
0 to 120 dB - 0.1dB step
Active aperture Up to 64* elements
Compliant with EN ISO 18563-1
F M C / T F M
TFM
Real-time, up to 128 elements
256 Kpi
Refresh rate
Up to 110 Hz at 65 Kpi
ATFM
(Adaptative TFM)
Real-time
FMC Recording capability
Modes
Direct, indirect and converted
modes
Image resolution Above 4 Mpi in post-processing
* Depends on the hardware configuration (32:128PR, 64:64PR or 64:128PR).
