29
C o n v e n t i o n a l U T
P u l s e r
Number of
channels
4 – up to 4 P/R or 2 P/C
Pulse type
Negative square pulse
Amplitude
From 12 to 200 V (1V)
Pulse width Pulse width from 30 to 1250 ns
False time < 5ns
R e c e i v e r
Number of
channels
4 – up to 4 P/R or 2 P/C
Input impedance
50Ω
Frequency range
Frequency range 0.6 to 25 MHz
Max. input signal
1.4 Vpp
Gain
0 to 120 dB - 0.1dB step
Compliant with EN ISO 12668-1
14. TECHNICAL SPECIFICATIONS
* Depends on the hardware configuration (32:128PR, 64:64PR or 64:128PR).
D i g i t i z e r
Amplitude resolution 16 bits
Real-time averaging
1 to 32
FMC A-scan range
8K max
Sampling frequency
Up to 100MHz
Signal processing Rectified, RF, Envelope
A-scan size Up to 65K samples
A c q u i s i t i o n
PRF Up to 40 KHz
Data throughput on SSD
Up to 180 MB/sec
A-scan and Peak recording
Data file size Limited by SSD capacity
Data compression Up to 32
“Live data missed”
information
