Quick Start Guide
– 3 –
8. Hardware Stacking Connection (Optional)
Plug one end of a 40GBASE-CR4 DAC cable in the bottom
QSFP+ port of the top unit.
Plug the other end of the DAC cable into the top QSFP+ port
of the next unit.
Repeat for each unit in the stack.
(Optional) Plug one end of a 40GBASE-CR4 DAC cable into
the bottom QSFP+ port on the bottom unit and the other
end into the top QSFP+ port on the top unit.
Reboot each switch in the stack to start stack operation.
Note: Stacking support is dependent on the switch
software. For stacking support information, refer to the NOS
software documentation.
1
2
3
4
5
Hardware Specifications
Switch Chassis
Size (W x D x H) 440 x 350 x 45 mm (17.32 x 13.78 x 1.77 inches)
Weight AS4610-30T: 5.16 kg (11.37 lb)
AS4610-30P: 6.02 kg (13.27 lb)
AS4610-54T: 5.38 kg (11.86 lb)
AS4610-54P: 6.36 kg (14.02 lb)
Temperature Operating: 0° C to 45° C (32° F to 113° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 5% to 95% (non-condensing)
150 W AC PSU (AS4610-30T/ AS4610-54T)
AC Input 100-240 VAC, 50-60 Hz, 3-1.5 A
Power Rating 150 W maximum
Size (W x D x H) 54.5 x 220 x 40.25 mm (2.15 x 8.66 x 1.58 inches)
600 W AC PSU (AS4610-30P)
AC Input 100-240 VAC, 50-60 Hz, 8.5-4.25 A
Power Rating 600 W maximum
Size (W x D x H) 54.5 x 220 x 40.25 mm (2.15 x 8.66 x 1.58 inches)
920 W AC PSU (AS4610-54P)
AC Input 100-240 VAC, 50-60 Hz, 13-6.5 A
Power Rating 920 W maximum
Size (W x D x H) 54.5 x 220 x 40.25 mm (2.15 x 8.66 x 1.58 inches)
Regulatory Compliances
Emissions EN 55022:2010, Class A
EN 61000-3-2:2009, Class A
EN 61000-3-3:2008
FCC Class A
VCCI Class A
CE Mark
CCC GB9254-2008 (AS4610-54P only)
BSMI (CNS13438)
Immunity EN 55024:2010
IEC 61000-4-2/3/4/5/6/8/11
Safety UL (CSA 22.2 No 60950-1 & UL60950-1)
CB (IEC/EN60950-1)
CCC GB4943-2011 (AS4610-54P only)
BSMI (CNS14336)
