Quick Start Guide
– 3 –
Hardware Specifications
Switch Chassis
Size (W x D x H) 440 x 350 x 44 mm (17.32 x 13.78 x 1.77 inches)
Weight 5.525 kg (12.18 lb)
Temperature Operating: 0° C to 45° C (32° F to 113° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 5% to 95% (non-condensing)
150 W AC PSU
AC Input 100-240 VAC, 50-60 Hz, 3-1.5 A
Power Rating 150 W maximum
Size (W x D x H) 54.5 x 220 x 40.25 mm (2.15 x 8.66 x 1.58 inch)
Regulatory Compliances
Emissions EN 55022:2010+AC:2011, Class A
EN 61000-3-2:2014, Class A
EN 61000-3-3:2013
FCC Class A
VCCI Class A
CE Mark
Immunity EN 55024:2010+A1:2015
IEC 61000-4-2:2008 ED.2.0
IEC 61000-4-3:2010 ED.3.2
IEC 61000-4-4:2012 ED.3.0
IEC 61000-4-5:2014 ED.3.0
IEC 61000-4-6:2013 ED.4.0
IEC 61000-4-8:2009 ED.2.0
IEC 61000-4-11:2004 ED.2.0
Safety UL (CSA 22.2 No 60950-1 & UL60950-1)
CB (IEC/EN60950-1)
