Hardware Specifications
Switch Chassis
Size (W x D x H) ECS4100-26TX/ECS4100-26TX-ME/
ECS4100-28T/ECS4100-52T: 44 x 22 x 4.4 cm
(17.32 x 8.66 x 1.73 in. )
Weight ECS4100-26TX: 2.2 kg (4.85 lb)
ECS4100-26TX-ME: 2.36 kg (5.20 lb)
ECS4100-28T: 2.2 kg (4.85 lb)
ECS4100-52T: 2.5 kg (5.5 lb)
Temperature Operating: 0 ° C to 50 ° C (32 ° F to 122 ° F)
Operating: 0 ° C to 45 ° C (32 ° F to 113 ° F,
ECS4100-52T only)
Storage: -40 ° C to 70 ° C (-40 ° F to 158 ° F)
Humidity Operating: 10% to 90% (non-condensing)
Power Specification
AC Input Power ECS4100-26TX: AC 100-240 V, 50/60 Hz, 1 A
ECS4100-28T: AC 100-240 V, 50/60 Hz, 1 A
ECS4100-52T: AC 100-240 V, 50/60 Hz, 1 A
AC-DC Power
Adapter
(ECS4100-26TX-
ME)
Input: AC 100-240 V, 50/60 Hz, 1 A
Output: 36-60 VDC, 2 A
Total Power
Consumption
ECS4100-26TX: 20 W
ECS4100-26TX-ME: 20 W
ECS4100-28T: 20 W
ECS4100-52T: 40 W
Regulatory Compliances
Emissions CE Mark
◆
EN 55022, Class A
FCC Class A
BSMI Certificate
Immunity IEC 61000-3-3, 61000-4-2/3/4/5/6/11
Safety UL/CUL(UL60950-1, CSA60950-1)
UL 60950-1, 2nd Edition, 2014-10-14
CAN/CSA C22.2 No. 60950-1-07, 2nd Edition,
2014-10
IEC 60950-1:2005 (2nd Edition); Am 1:2009+
Am 2:2013
EN 60950-1:2006+A11:2009+A1:2010+A12:2011
+A2:2013
CB (IEC/EN 60950-1)
BSMI CNS14336-1
