Chapter 2
| Installation Overview
Switch Installation Tasks
– 19 –
Ground the Switch and Power On
Connect a ground wire to the switch, and then use a AC power cable to connect the
switch to a AC power source..
Go to the chapter “Power and Grounding”.
Figure 4: Connecting AC Power
Connect DC Power
Connect a ground wire to the switch, and then use a DC power cable to connect the
switch to a DC power source.
Go to the chapter “Power and Grounding”.
Figure 5: Connecting DC Power
Connect a grounding wire to the grounding terminal..
Connect an external AC power source to the AC power socket of the switch using the supplied
AC power cord.
Connect a grounding wire to the grounding terminal..
Connect an external DC power source to the DC power socket of the switch using a DC power
cable.
